Hazardous Locations
IR7 Series
Compact explosion-proof LED fixture with high-impact aluminum construction for space-constrained hazardous installations.
CLASS 1 DIVISION 1 GROUPS C D
CLASS 2 DIVISION 2 GROUPS E F G
UL 844 Hazardous Locations
UL 924 Emergency Lighting
UL 1598A Marine Outside Type
ABS
Request a Quote
Or call us: 1-800-373-6314
Applications
- Petrochemical Facilities
- Lubrication Pits
- Oil Drilling Rigs
- Crew Quarters
- Solvent/Cleaning Areas
- Processing Plants
- Water Treatment Areas
- Marine Loading Docks
Specifications
- Construction
- Corrosion resistant marine grade copper free aluminum heavy gauge extruded reflectors with high gloss reflective finish
- Hardware
- Stainless steel bolts
- Lens
- Explosion-proof impact and heat resistant glass tubes
- Light Source
- 17W 35W 40W 54W 60W LED -- LED ARRAY 40W each 4000 nominal lumens per strip
- Power
- 120-277v 50/60Hz UNV
- Ambient Temp
- 40C maximum
- Mounting
- Ceiling or pendant
- Weight
- 2 foot 50 lbs, 4 foot 60 lbs, 4 foot 4 lamp 120 lbs
Key Features
- Field replaceable LED circuit boards and drivers with quick disconnects
- Convenient wiring access through screw-cap covers
- Factory sealed
5 year warranty on LED
